* Created by Windows Sockets Recorder
*
* Created on: Wed Jun 16 11:06:06
*********************************************************************/
#include "lrs.h"
Action()
{
int rc=0;
char *Data, *p,*q;
int Size;
char index[2];
char hexStr[20]={0};
char strByte[20]={0};
unsigned char hexByte[20]={0};
unsigned char *unitptr;
char rSeqNum[20] = {0};
int len = 0;
int i,j,k,ret;
int z = 0;
//设定开始事务
len = strlen(lr_eval_string("{seqNum_6}"));
p = lr_eval_string("{seqNum_6}") ;
ret = str2hex(rSeqNum,6,p);
lr_output_message("str=%s, len = %d",p, ret);
lr_output_message("str=%s, len = %d",rSeqNum, ret);
HexStrTobyte(p,hexByte,&len);
for (i =0;i < len ; i++){
lr_output_message("str=%02x,",hexByte[i]);
}
q = hexStr;
lr_output_message("str=%s",p);
len = strlen(p);
for (j=0; j<len/2 ; j++){
memcpy(q,"\\x",2);
memcpy(q+2, p,2);
p+=2;
q+=4;
}
lr_output_message("str=%s",hexStr);
lr_save_string(hexStr,"seqN");
#if 1
lrs_startup(257);
//创建socketS
lr_start_transaction("create_socket");
//
rc = lrs_create_socket("socket0", "TCP", "RemoteHost=127.0.0.1:32001", LrsLastArg);
//判断套接字创建是否成功
if (rc==0){
lr_end_transaction("create_socket", LR_PASS);
lr_output_message("Socket was successfully send ");
}
else{
lr_end_transaction("create_socket", LR_FAIL);
lr_output_message("An error occurred while closing the socket, Error Code: %d", rc);
}
//判断socket是否链接成功的事务，0表示创建成功
lr_start_transaction("send_socket");
//发送安全会话建立请求buf0为在data.ws中定义的发送变量
lrs_send("socket0", "buf0", LrsLastArg);
//设置连接超时时间为1秒
lrs_set_recv_timeout(45,0);
if (rc==0){
lr_end_transaction("send_socket", LR_PASS);
lr_output_message("Socket was successfully send ");
}
else{
lr_end_transaction("send_socket", LR_FAIL);
lr_output_message("An error occurred while send the socket, Error Code: %d", rc);
}
//设置接收超时时间为1秒
//lrs_set_recv_timeout2(45,0);
lr_output_message("Socket was successfully send");
//接收消息，存放在buf1中，buf1是在data.ws中定义的接收数组，注意数组长度一定要大于等于实际接收长度
lrs_receive("socket0", "buf1", LrsLastArg);
//把Socket最后接收的字节数组，长度放在recvlen中，内容放在recvbuf中
//lrs_get_last_received_buffer("socket0",&recvbuf,&recvlen);
lr_start_transaction("received_socket");
//lrs_save_param("socket0", NULL, "F39", 39, 2);
//lr_message ("F39: %s", lr_eval_string("{F39}"));
lrs_get_last_received_buffer("socket0",&Data,&Size);
//lr_message("报文内容:%s",Data);
//lr_message("应答码第39位:%x",Data[39]);
//lr_message("应答码第40位:%x",Data[40]);
//获取流水号000000
if(Size == 116){
lr_output_message("接收报文长度 116 == %d", Size);
lr_end_transaction("received_socket", LR_PASS);
}else{
lr_output_message("接收报文长度不够116 != %d", Size);
lr_end_transaction("received_socket", LR_FAIL);
}
//memcpy(F39,lr_eval_string("{F39}"),2);
//lr_output_message("recvbuf: %X",recvbuf);
lr_start_transaction("ITMP-9121-A0-33");
//获取流水号000000
//if(Data[32]==0x45&&Data[33]==0x34){
memcpy(rSeqNum, Data+31,3);
if(!memcmp(Data+31,hexByte,3)){
lr_log_message("流水号位：%3.3s",Data+32);
lr_output_message("交易流水一致");
lr_end_transaction("ITMP-9121-A0-33", LR_PASS);
}else{
lr_log_message("流水号4位：%x",Data[33]);
lr_output_message("交易流水不一致");
lr_end_transaction("ITMP-9121-A0-33", LR_FAIL);
}
lr_start_transaction("ITMP-9121-A0");
//获取应答码000000
if(Data[39]==0x41&&Data[40]==0x30){
lr_output_message("交易成功");
lr_end_transaction("ITMP-9121-A0", LR_PASS);
}else{
lr_output_message("交易失败");
lr_end_transaction("ITMP-9121-A0", LR_FAIL);
}
//关闭socket
lrs_close_socket("socket0");
//lrs_free_buffer(lseqNum);
#endif
return 0;
}
void test_printf5(char *str, int length)
{
int iii;
printf("the str is:");
for (iii = 0; iii < length; iii++)
{
printf("%02x ", str[iii]);
}
printf("\n");
}
/*str to hex,
字符串转换为16进制
利用snprintf 函数
int snprintf(char* dest_str,size_t size,const char* format,...);
功能:将可变参数以format的格式转换到dest_str中，并可以用%s打印出来。
1、dest_str:目标字符串，即输出字符串
2、size: 转换字符控制长度。
(1) 如果格式化后的字符串长度 < size，则将此字符串全部复制到str中，并给其后添加一个字符串结束符('\0')；
(2) 如果格式化后的字符串长度 >= size，则只将其中的(size-1)个字符复制到str中，并给其后添加一个字符串结束符('\0')，返回值为欲写入的字符串长度。
3、format :转换为某个格式，例如：%2d,%04X,%02X。
4、...:需要转换的字符串
*/
int str2hex(char *out_string, int length, char *in_string)
{
int index;
char *fmt = "%02x";
for (index = 0; index < length; index++)
{
snprintf((char *)&out_string[index << 1], 3, fmt, in_string[index]);
}
return (length << 1);
}
int HexStrTobyte(char *str, unsigned char *out, unsigned int *outlen)
{
char *p = str;
char high = 0, low = 0;
int tmplen = strlen(p), cnt = 0;
tmplen = strlen(p);
while (cnt < (tmplen / 2))
{
high = ((*p > '9') && ((*p <= 'F') || (*p <= 'f'))) ? *p - 48 - 7 : *p - 48;
low = (*(++p) > '9' && ((*p <= 'F') || (*p <= 'f'))) ? *(p)-48 - 7 : *(p)-48;
out[cnt] = ((high & 0x0f) << 4 | (low & 0x0f));
p++;
cnt++;
}
if (tmplen % 2 != 0)
out[cnt] = ((*p > '9') && ((*p <= 'F') || (*p <= 'f'))) ? *p - 48 - 7 : *p - 48;
if (outlen != NULL)
*outlen = tmplen / 2 + tmplen % 2;
return tmplen / 2 + tmplen % 2;
}
int byteToHexStr(unsigned char byte_arr[], int arr_len, char *HexStr, int *HexStrLen)
{
int i, index = 0;
for (i = 0; i < arr_len; i++)
{
char hex1;
char hex2;
int value = byte_arr[i];
int v1 = value / 16;
int v2 = value % 16;
if (v1 >= 0 && v1 <= 9)
hex1 = (char)(48 + v1);
else
hex1 = (char)(55 + v1);
if (v2 >= 0 && v2 <= 9)
hex2 = (char)(48 + v2);
else
hex2 = (char)(55 + v2);
if (*HexStrLen <= i)
{
return -1;
}
HexStr[index++] = hex1;
HexStr[index++] = hex2;
}
*HexStrLen = index;
return 0;
}
